Payload & Center of Mass (COG)
This section defines the center of gravity (COG) and payload for the SD/SDV-Series screwdriver tools.
The values are intended for robot configuration and dynamic load calculations.
Reference Coordinate System
The coordinate system used for calculating the center of mass is shown below.
The reference point is located at the tip of a 50 mm screwdriver bit (or teach pointer).
Note
The values represent a typical configuration with:
Safety shield mounted
50 mm bit installed
No screw attached
Center of Gravity (COG)
CX (mm) |
CY (mm) |
CZ (mm) |
|
|---|---|---|---|
SD/SDV35 |
-2 |
-54 |
79 |
SD/SDV50 |
-2 |
-54 |
79 |
SD/SDV70 |
-2 |
-54 |
79 |
SD/SDV120 |
-2 |
-52 |
80 |
Payload
Model |
Payload |
|---|---|
SD/SDV35 |
2.6 kg (5.73 lbs) |
SD/SDV50 |
2.6 kg (5.73 lbs) |
SD/SDV70 |
2.6 kg (5.73 lbs) |
SD/SDV120 |
2.7 kg (5.95 lbs) |
Usage in Robot Configuration
The payload and COG values must be configured in the robot controller to ensure correct motion planning and safe operation.
Incorrect configuration may result in:
Reduced positioning accuracy
Increased wear on the robot
Unexpected motion behavior
Important Considerations
Note
The actual COG and payload may vary depending on:
Bit length and type
Screw size and weight
Vacuum tubing and fittings
Mounted accessories
The integrator is responsible for validating the final configuration.
Important
Always verify robot payload limits and dynamic performance when operating at high speeds or accelerations.
