SD70 Specifications

Mechanical dimension of the SD70 tool with the safety shield in its two extreme positions. All dimensions are in mm/[inch].

../../../_images/sd_70_mechanical.png

SD70 dimension - fully retracted safety shield. All dimensions are in mm/[inch].

../../../_images/sd_70_mechanical_retracted.png
