SD35 Specifications

Mechanical dimension of the SD35 tool with the safety shield in its two extreme positions. All dimensions are in mm/[inch].

../../../_images/sd_35_mechanical.png

SD35 dimension - fully retracted safety shield. All dimensions are in mm/[inch].

../../../_images/sd_35_mechanical_retracted.png
