Payload & Center of Mass (COG)
The coordinate system used for calculating the moment of inertia and center of mass for the screwdriver is shown below. All values represent a typical configuration with the safety shield covering a 50 mm bit with no screw attached.
COG |
COG(mm) - at tip of 50mm screwdriving bit or teach pointer |
||
|---|---|---|---|
CX |
CY |
CZ |
|
SD35 |
0 |
-47 |
80 |
SD70 |
0 |
-57 |
82 |
Payload |
|
|---|---|
SD35 |
2.40 kg / 53 lb |
SD70 |
2.50 kg / 55 lb |
